Характеристики
| Параметр |
Значение |
| microphone inputs | input impedance: |
3 ㏀ |
| MPN: |
MOSC0029UK |
| headphone outputs | dynamic range [a-weighted: |
104 dB |
| other I/O | S/PDIF I/O: |
2 × phono [RCA] or via optical I/O selected via Focusrite Control |
| analogue inputs 1 and 2 | mic /instrument switching: |
2 × front panel switches or via Focusrite Control 2 |
| headphone outputs | output impedance: |
1 Ω |
| Black Lion Audio Modification MPN: |
BLMScar18i20 |
| instrument inputs | gain range: |
56 dB |
| Form Factor: |
Desktop, Rack Mountable |
| line inputs | gain range: |
56 dB |
| microphone inputs | gain range: |
56 dB |
| Maximum Sampling Rate: |
24 Bit (192 kHz) |
| instrument inputs | dynamic range [a-weighted: |
110 dB |
| instrument inputs | frequency response: |
20 Hz ? 20 kHz ± 0.1 dB |
| instrument inputs | maximum input level [at minimum gain: |
9 dBu |
| line outputs | maximum output level: |
15.5 dBu |
| analogue inputs 3 to 8 | connectors: |
XLR Combo: Mic / Line, on rear panel |
| microphone inputs | frequency response: |
20 Hz ? 20 kHz ± 0.1 dB |
| other I/O | word clock output: |
BNC connector |
| headphone outputs | frequency response: |
20 Hz ? 20 kHz ± 0.1 dB |
| analogue outputs | stereo headphone outputs: |
2 × 6.35 mm TRS jack on front panel |
| analogue inputs 1 and 2 | mic / line switching: |
automatic |
| line outputs | frequency response: |
20 Hz ? 20 kHz ± 0.1dB |
| line inputs | frequency response: |
20 Hz ? 20 kHz ± 0.1dB |
| headphone outputs | maximum output level: |
7 dBu |
| other I/O | optical I/O: |
4 × TOSLINK optical; 8 at 44.1 / 48 kHz or 4 at 88.2 / 96 kHz |
| other I/O | MIDI I/O: |
2 × 5-pin DIN sockets |
| instrument inputs | input impedance: |
1.5 ㏁ |
| microphone inputs | dynamic range [a-weighted: |
111 dB |
| line outputs | dynamic range [a-weighted: |
108 dB |
| line inputs | input impedance: |
60 ㏀ |
| Производитель: |
Focusrite |
| line inputs | maximum input level [at minimum gain: |
22 dBu |
| Тип: |
USB Audio Interface |
| line inputs | dynamic range [a-weighted: |
110.5 dB |
| line outputs | output impedance: |
430 Ω |
| analogue inputs 1 and 2 | phantom power: |
shared +48 V phantom power switch for inputs 1 to 4 |
| analogue inputs 3 to 8 | mic / line switching: |
automatic |
| microphone inputs | maximum input level [at minimum gain: |
9 dBu |
| analogue outputs | main outputs: |
10 × balanced 6.35 mm TRS jacks on rear panel |
| Модель: |
Scarlett 18I20 3rd Generation |
| microphone inputs | noise EIN [a-weighted: |
-128 dBu |
| analogue inputs 3 to 8 | phantom power: |
shared +48 V phantom power switches for inputs 1 to 4 and 5 to 8 |
| Country of Origin: |
Malaysia |
| analogue inputs 1 and 2 | connectors: |
XLR Combo type: Mic / Line / Instrument, on front panel |
| Универсальный товарный код: |
613816421381 |
